Technical data for the wireless modules
105542_en_05 PHOENIX CONTACT 169 / 198
RAD-DAIO6-IFS (2901533):
Do not use the analog loop power output (PWR1).
Only use the analog voltage output (U1).
Do not use more than two of the four possible digital inputs and outputs.
Operating conditions for the extended temperature range (+55°C ... 70°C)
No function restrictions for the extended temperature range if you keep a minimum spacing of 17.5 mm
between the modules. The minimum spacing is the width of a DIN rail connector.
Otherwise, please observe the following restrictions. Individual operating conditions available on request!
