3.6.2 Terminating the RS-485 bus cable
The wireless modules are operated on a 2-wire bus cable. RS-485 bus connections must
be terminated at both ends with a 390/150/390  termination network.
• Depending on the position of the device on the RS-485 bus cable, activate or deactivate
the termination network.
Figure 3-8 DIP switch
3.6.3 RS-485 pin assignment
In RS-485 mode, you can create a network with several I/O devices. Use a twisted pair bus
cable to connect the I/O devices. Fit this bus cable with a termination network at the two fur-
thest points.
• Connect the single wires of the data cable to the COMBICON plug-in screw terminal
block (Figure 3-1, item 10).
• Make sure the signal assignment is correct.
Figure 3-9 RS-485 interface pin assignment
Table 3-1 DIP switches 1 and 2: termination network
DIP switch
Device position Ter mi n at i on ne t wor k 1 2
RS-485 termination device On ON ON
RS-485 device Off OFF OFF
