6.6.8 RAD-DAIO6-IFS process data
30xx2 ... 30xx9 Reserved
40xx1 Digital outputs DO1 ... DO8
Channel (high byte) Channel (low byte)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Reserved DO
8
DO
7
DO
6
DO
5
DO
4
DO
3
DO
2
DO
1
Terminal point
5.x 5.x 4.x 4.x 3.x 3.x 2.x 2.x
40xx2 ... 40xx9 Reserved
I/O module Module type ID Register Address range Function code
RAD-DAIO6-IFS 60
hex
03
hex
(inputs)
30xx0 ... 30xx2
1
1
xx = I/O MAP address set using the white thumbwheel
fc 04
03
hex
(outputs)
40xx0 ... 40xx2
1
fc 03, 16
Table 6-16 RAD-DAIO6-IFS module type and timeliness of data
30xx0
1
1
xx = I/O MAP address set using the white thumbwheel
Module type and timeliness of data
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Y
2
2
Y = timeliness of data, bit 8
If the data in the register is not up to date, then the register value is 1. If the process data has been written
to one of the registers, bit 8 in 40xx0 is set to 0. The value in register 40xx0 then remains 0 for the entire
operating time of the device. This is the case, for example, if the wireless connection fails. The IN process
data is retained in the Modbus table, but is no longer updated.
Module type
3
3
If the module type in the register is invalid or not available, then the register value is 0.
