6.6.7 RAD-DO8-IFS process data
I/O module Module type ID Register Address range Function code
RAD-DO8-IFS 11
hex
02
hex
Outputs
40xx0 ... 40xx1
1
1
xx = I/O MAP address set using the white thumbwheel
fc 03, 16
02
hex
Short circuit
detection
30xx0 ... 30xx1
1
fc 04
Table 6-15 RAD-DO8-IFS module type and timeliness of data
30xx0, 40xx0
1
1
xx = I/O MAP address set using the white thumbwheel
Module type and timeliness of data
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Y
2
2
Y = timeliness of data, bit 8
If the data in the register is not up to date, then the register value is 1. If the process data has been written
to one of the registers, bit 8 in 40xx0 is set to 0. The value in register 40xx0 then remains 0 for the entire
operating time of the device.
However, in register 30xx0, bit 8 is reset to 1 as soon as the status of short-circuit detection is not up to
date. This is the case, for example, if communication with an input module fails. In this case, the IN process
data is retained in the Modbus table, but is no longer updated.
Module type
3
3
If the module type in the register is invalid or not available, then the register value is 0.
30xx1 Short-circuit detection at the digital outputs
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Reserved X
1
1
Bit 1 = 1: short circuit detected at one output or several outputs 5 ... 8.
X
2
2
Bit 0 = 1: short circuit detected at one output or several outputs 1 ... 4.
