12 13
3. Preparing the charger
Select the adapter that corresponds to your country.
a) Insert the top round end of the
adapter into the round corner of
the power supply.
b) Click the bottom end of the adapter
in to lock into place.
c) To remove, pull back the tab on the
power supply.
d) Pull the adapter upwards to remove
it.
3.1 Setting up the power supply
UK AUS US EU
a
b
c
d
a) Plug the larger end of the charging cable into the power
supply.
b) Plug the smaller end into the micro-USB port on the
charger.
c) Plug the power supply into a power outlet.
d) The indicator light is green when the charger
is connected to the power supply.
3.2 Connecting the power supply
a
b
d
c
