12 AM240/240D
THD (Any output, 1KHz @ +14dBu, 20Hz to
20KHz, channel inputs)
<0.005% <0.005%
CMRR (1 KHz @ -60dBu, Gain at maximum)
80 dB 80 dB
Maximum Level
Mic Preamp Input
+10 dBu +10 dBu
All Other Input
+22 dBu +22 dBu
Balanced Output
+28 dBu +28 dBu
Impedance
Mic Preamp Input
2 K ohms 2 K ohms
All Other Input (except insert)
10 K ohms 10 K ohms
RCA 2T Output
1.1 K ohms 1.1 K ohms
Equalization
3-band, +/-15 dB 3-band, +/-15 dB
Low EQ
80 Hz 80 Hz
Mid EQ
2.5 KHz 2.5 KHz
Hi EQ
12 KHz 12 KHz
Low Cut Filter
75Hz (-18 dB/oct) 75Hz (-18 dB/oct)
32/40 bit Digital Effect Processor
N/A
100 effects with tap delay
control
Power Requirement (external power supply,
depends on region)
100VAC, 120VAC,
220 ~ 240VAC, 50/60Hz
100VAC, 120VAC,
220 ~ 240VAC, 50/60Hz
Weight
1.5 kg (3.3 lbs) 1.5 kg (3.3 lbs)
Dimensions (WxHxD) 190 x 56 x 233 mm
(7.48” x 2.2” x 9.17”)
190 x 56 x 233 mm
(7.48” x 2.2” x 9.17”)
