AM844D USB
English
SPECIFICATIONS
Inputs
Total Channels 12
Balanced Mono Mic / Line Channel 8
Balanced Mic / Stereo Line channel 2
Balanced Stereo Line Channel 2
AUX Return 4 stereo
2T Input Mini stereo and stereo RCA
Outputs
Main L/R Stereo 2 x 1/4” TRS, Bal. & 2 x XLR
Group 8
Rec Out Mini stereo and stereo RCA
CTRL RM L/R 2 x 1/4” TS
Phones 2
Channel Strips 12
EFX Send 4
Pan/Balance Control Yes
Volume Controls 60mm fader
Inserts 8
Master Section
Phones Level Control Yes
Main L/R Level Control 60 mm fader
Level Meter 13-segment
Phantom Power Supply +48V DC
Frequency Response (Mic input to any output)
20Hz ~ 60KHz +0/-1 dB
20Hz ~ 100KHz +0/-3 dB
Crosstalk (1KHz @ 0dBu, 20Hz to 20KHz bandwidth, channel in to main L/R outputs)
Channel fader down, other channels at unity <-90 dB
Noise (20Hz~20KHz; measured at main output, Channels 1-4 unit gain; EQ at; all channels on main mix; channels 1/3 as far left as
possible, channels 2/4 as far right as possible. Reference=+6dBu)
Master @ unity, channel fader down -86.5 dBu
Master @ unity, channel fader @ unity -84 dBu
S/N ratio, ref to +4 >90 dB
Microphone Preamp E.I.N. (150 ohms terminated, max gain) <-129.5 dBm
