9
AM844D USB
English
THD (Any output, 1KHz @ +14dBu, 20Hz to 20KHz, channel inputs) <0.005%
CMRR (1 KHz @ -60dBu, Gain at maximum) 80dB
Maximum Level
Mic Preamp Input +10dBu
All Other Input +22dBu
Balanced Output +28dBu
Impedance
Mic Preamp Input 2 K ohms
All Other Input (except insert) 10 K ohms
RCA 2T Output 1.1 K ohms
Equalization 3-band, +/-15dB
Low EQ 80Hz
Mid EQ 100-8k Hz, sweepable
L-Mid EQ 800 Hz
H-Mid EQ 3 kHz
Hi EQ 12 kHz
Low Cut Filter 75 Hz (-18 dB/oct)
USB Audio Stereo In/Out
Connector Type USB Type B
Bitrate 16-bit
Sampling Rate 48 kHz
Digital Effect Processor 16 effects with parameter control
Footswitch EFX on/off
Power Requirements 100-240 VAC, 50/60 Hz
Dimensions (WxHxD) 418 x 140 x 438 mm (16.5” x 5.5” x 17.25”)
Weight 5.9 kg (13 lbs)
