6. Output[x] [Name] Limiter
A: 5ms R: 0.2s +20dB
-> A: 5ms R: 0.2s +20dB [Atk time] 5ms [Rel time] 0.1s [Amp.] -10.0 dB
: : :
200ms 3.0s +20.0dB (OFF)
7. Output[x] [Name] Delay
Delay = 0.000 ms
-> Delay = 0.000 ms PM1 N/A 000.0000mS 000.0000mS
[1 ms steps] [20.8 us steps]
600.0000mS 000.9984mS
8. Output[x] [Name] Polarity
Polarity = Normal
-> Polarity = Normal PM1 N/A Normal Same as PM2
Invert
9. Output[x] [Name] HPF
Y F = 20.0 Hz (Y = Bypass OR Filter Type/Order, where lter type can be Buttw_1st, Buttw_2nd,
LRiley_2nd, Bessel_2nd, Buttw_3rd, Buttw_4th, Lriley_4th, Bessel_4th,
Custom_2nd, Custom_3rd, Custom_4th)
-> Y F = 20.0 Hz Freq Fast Selection [Filt Type] Bypass [Freq.] 20Hz
ONLY in Freq Editing Mode : :
Custom_4th 20kHz
Through the PM2, it is possible to Bypass the lter or to select one of the 11 available
lters' type/orders, and through the PM3 to set the HP cutting Frequency (quick ne tuning by 1Hz steps).
Once selected the lter Type and pressing again the ENTER button can be accessed the selected
lter's Fast Freq. Selection page.
9.1 Output[x] [Name] HPF
-> Y F = 20.0 Hz
9.1a. If you selected a lter from Buttw_1st up to Bessel_4th, then
the lter's Cutting Frequency can be set as follow:
Output[x] [Name] HPF [Thousands Editor] [Hundreds Editor] [Units Editor]
-> Edit Freq = 250Hz [Freq.] 1000Hz [Freq.] 100Hz [Freq.] 1Hz
: : :
20000Hz 900Hz 100Hz
9.1b. If you selected a Custom Filter (from 2
nd
up to 4
th
order), depending
from the lter's order, the cascade of second order Cells building
the lter are available for editing in their Freq and Q parameter,
indepndently.
For proceeding with the editing of a custom lter Cell, the PM1 is
here used foir the Cell selection.
