4 UTILITY MENU:......
<< Security Utilities >>
3.1 SECURITY UTILITY: Parameter will
Show Parameter be shown *
not be shown
3.2 SECURITY UTILITY: Lock Unit
Lock Unit Lock: Off *
Lock: On
3.3 SECURITY UTILITY: User Password
User Password [ ]
3.4 SECURITY UTILITY: Enable Password (For the details about the Password Setting/Enable
Enable Password Password: Enable and Unit Lock, , refer to the “Utility Menus Use”
Password: Disable * Section)
Input Channels Editing
By pushing either the A or B Input channel buttons and holding the buttons down for at least 2 seconds, you can access the different
parameters for their respective input channels.
NAV/PM1 Encoder NAV/PM1 Enc. PM2 Enc. PM3 Enc.
[to navigate between menus] [to chose values for the parameters, no need to conrm the chosen values,
which are automatically loaded during the encoders use]
1. Input A/B Source
Source = Analog
-> Source = Analog PM1 N/A Analog Same as PM2
Digital
Pink Noise
2. Input A/B Ngate [The full editing of the Noise Gate parameters is available from Pc Sw Remote
Control;the desired setting can be stored in the unit and recalled when selected
“On” from the front panel, or deactivated when selected “Off”]
Noise Gate Byp = On
-> Noise Gate Byp = On PM1 N/A On Same as PM2
Off
3. Input A/B Gain
Gain = + 0.0 dB
-> Gain = + 0.0 dB PM1 N/A -15 db Same as PM2
:
+15 dB
4. Input A/B AGC [The full editing of the Automatic Gain Controller parameters is available from
Pc Sw RemoteControl; the desired setting can be stored in the unit and recalled
when selected “On” from the front panel, or deactivated when selected “Off”]
AGC Byp = On
-> AGC Byp = On PM1 N/A On Same as PM2
Off
5. Input A/B Delay
Delay = 0.000 ms
-> Delay = 0.000 ms PM1 N/A 000.0000mS 000.0000mS
[1 ms steps] [20.8 us steps]
600.0000mS 000.9984mS
ESC
ENTER
ESC
ENTER
ESC
ENTER
ESC
ENTER
