6. Input A/B Sel EQ
Select EQ = GEQ 15 bands
-> Select EQ = GEQ 15 Bands PM1 N/A GEQ 15 Bands Same as PM2
PEQ 7 Bands
7. Input A/B EQ Byp
EQ Bypass = Off
-> EQ Bypass = Off PM1 N/A Off Same as PM2
On
8. The Menu 8 accessing the Filters paramenters, changes depndently form the EQ selected at the step 6:
Graphic 15 Bands OR Parametric 7 Bands
If the “GEQ 15 Band” option is select in point 6 AND set to Bypass OFF in point 7.
8.A. Input A/B GEQ
Graphic Equalizer (The 15 available lters are all Peaker ones with xed Q=2.2, for granting the 2/3 of Oct width,
+-12dB att/gain range and centered at the following frequenices: 25Hz, 40Hz, 63Hz, 100Hz, 160Hz,
250Hz, 400Hz, 630Hz, 1kHz, 1.6kHz, 2.5kHz, 4kHz, 6.3kHz, 10kHz, 16kHz)
-> 25Hz 0.0dB Q=2.2 25Hz -12dB Same as PM2
: :
+12dB Same as PM2
..:
-> 16kHz 0.0dB Q=2.2 16kHz -12dB Same as PM2
: :
+12dB Same as PM2
If the “PEQ 7 Band” option is selected in point 6 AND set in Bypass OFF in point 7.
8.B. Input A/B PEQ[x] (X from 1 to 7, selectable through the PM1 Encoder)
Parametric Equalizer
8.B.1 Input A/B PEQ [x] (Byp can be set On or Off through the use of the PM2 Encoder)
-> Byp = Off Type = Y (Y = Peaking_Eq, Hi-Shelv_Q, Lo-Shelv_Q, selectable through the PM3 Encoder)
8.B.1a. If you selected a Peaking_Eq lter, then the lter can be set by
the following parameters
Input A/B PEQ[x] (up to 7 lters available)
[Freq] [Gain] [Q]
-> 1000Hz +0.0dB Q=1.00 [Freq.] 20Hz [Amp.] -12.0 dB [Q] 0.30
: : :
20kHz [1Hz Step] +12.0 dB 20.00
8.B.1ab Input A/B PEQ[x]
[Freq]
-> Edit Freq = 1000Hz PM1 N/A [Freq.] 20Hz [Freq.] 20Hz
: :
20kHz [10Hz Step] 20kHz [1Hz Step]
8.B.1b. If you selected a Hi-Shelv_Q (variable Q High Shelving) lter,
then the lter can be set by the following parameters
Input A/B PEQ[x] (up to 7 lters available)
[Freq] [Gain] [Q]
-> 1000Hz +0.0dB Q=1.00 [Freq.] 20Hz [Amp.] -12.0 dB [Q] 0.30
: : :
20kHz [1Hz Step] +12.0 dB 20.00
