SPECIFICATIONS
MX 300/306
Input 3 phono, 3 line, 3 mic
Output 1 master, 1 rec, 1 booth via RCA
Minimum Input Voltage
Phono 3.2mV RMS, 47kOhms
Line 150mV RMS, 47kOhms
Microphone 3mV RMS, 2.2kOhms
Output Voltage
Line 7V RMS max.
Headphone 0.4V
Frequency Range +/-3 dB
Phono 20Hz ~2KHz,
Line 10Hz ~50KHz,
Microphone 20Hz ~20KHz,
Distortion <0.05%
S/N Ratio
Phono -50dB
Line -64dB
Microphone -60dB
Talkover Attenuation -14dB
Headphones Impedance 8 Ohms
Tone Control
Treble 40KHz, -30dB~15dB
Middle 1KHz, -30dB~15dB
Bass 40Hz, -30dB~15dB
Dimension (W x D x H) 254 x 320 x 99(mm)
Weight 3.5(kg)
Power Supply 115/230 V, 50/60Hz
Power consumption 30 W
