8 MX300 XE
SPECIFICATIONS
MX300 XE
Input 3 phono, 3 line, 3 mic
Output
1 master, 1 rec
1 booth via RCA
Minimum Input Voltage
Phono 3.2mV RMS, 47kOhms
Line 150mV RMS, 47kOhms
Microphone 3mV RMS, 2.2kOhms
Output Voltage
Line 7V RMS max
Headphones 0.4V
Frequency Range +/-3 dB
Phono 20Hz ~ 2KHz
Line 10Hz ~ 50KHz
Microphone 20Hz ~ 20KHz
Distortion <0.05%
S/N Ratio
Phono -50dB
Line -64dB
Microphone -60dB
Talkover Attenuation -14dB
Headphones Impedance 8 Ohms
Tone Control
Treble 40KHz,-30dB ~ 15dB
Middle 1KHz,-30dB ~ 15dB
Bass 40Hz,-30dB ~ 15dB
Dimension (W x D x H) 254x 320 x99 (mm)
Weight 3.5 (kg)
Power Supply 115/230V, 50/60Hz
Power consumption 30 W
