5) System Two (Stereo):
This conguration uses a Phonic wireless
microphone and mixer with Stand Alone Wireless
Transmitter Module (WM 60) transmitting the
source signals to ve "virtually" daisy chained
Performer active speakers. You can use a Phonic
VHF or UHF wireless microphone with wireless
module to transmit to the speakers. Set the
WIRELESS/WIRELESS MIC Switch in (down) on
the back of all the speakers. Speaker
1
has two
wireless modules installed in the two compartments
on the top of the speaker. One compartment is
tted with the matched-frequency wireless module
for the UHF or VHF wireless microphone. The
other compartment is tted with a Transmitter
& Receiver Module (WM 50) for receiving the
transmission from the Stand Alone Wireless
Transmitter Module (WM 60) and re-transmitting
it to the next speakers in the series. Speaker
1
re-transmits the VHF / UHF wireless microphone
signal to Speaker
2
, and the wireless microphone
and mixer signals to Speaker
3
. Speakers
2
and
3
both are tted with a Transmitter & Receiver
Module (WM 50) and they re-transmit the signals
to Speakers
4
and
5
, respectively. Speakers
4
and
5
each are tted with a Wireless Receiver
Module (WM 40) to receive the transmission from
Speakers
2
and
3
, respectively. This setup allows
all the speakers to instantly receive the wireless
microphone and mixer signals. You also are able to
play the mixer signals in stereo image because the
WM 60 auto-detects left- and right-side speakers.
(To install wireless modules please refer to the
instructions on page 15.)
Related Products: UM 11, UM 22, VM 11, VM 22,
WM 30, WM 40, WM 50, WM 60
