Frequency Response (Mic input to any output)
20Hz ~ 60KHz +0/-1 dB
20Hz ~ 100KHz +0/-3 dB
Crosstalk (1KHz @ 0dBu, 20Hz to 20KHz bandwidth, channel in to main L/R outputs)
Channel fader down, other channels at unity <-90 dB
Noise (20Hz~20KHz; measured at main output, Channels 1-4 unit gain; EQ at; all channels on main mix; channels 1/3 as far left as
possible, channels 2/4 as far right as possible. Reference=+6dBu)
Master @ unity, channel fader down -86.5 dBu
Master @ unity, channel fader @ unity -84 dBu
S/N ration, ref to +4 >90 dB
Microphone Preamp E.I.N. (150 ohms terminated, max
gain)
<-129.5 dBm
THD
Power output, 1KHz, 20Hz to 20KHz, @50 watts, 4 ohms <0.1%
Any output, 1KHz @ +14dBu, 20Hz to 20KHz, channel inputs <0.005%
CMRR (1 KHz @ -60dBu, Gain at maximum) 80 dB
Maximum Level
Mic preamp input +10 dBu
All other input +22 dBu
Unbalanced Output +22 dBu
Impedance
Mic preamp input 2 K ohms
All other input (except insert) 10 K ohms
RCA 2T output 1.1 K ohms
Equalization 3-band, +/-15 dB
Low EQ 80 Hz
Mid EQ 2.5 KHz
Hi EQ 12 KHz
Low cut lter 75Hz (-18dB/oct)
Power Requirement(depends on region) 100VAC, 120VAC, 220~240VAC, 50/60Hz
Power consumption (average max.) 100W
Dimensions (WxHxD) 275x100x270.3 mm (10.8”x3.9”x10.6”)
Net Weight 3.2 kg (7 lbs)
