PHONIC CORPORATION POWERPOD User's Manual
Graphic EQ Stereo 7-band 2 x 7-band (assignable
to Main 1 / Main 2)
ST+1 (assignable to
main L & R), 10-band
ST+1 (assignable to
main L & R), 10-band
Center Frequency 60, 120, 360, 1K,
2.5K, 7K, 16 KHz
60, 120, 360, 1K, 2.5K,
7K, 16K Hz
40, 80, 160, 315, 630,
1.25K, 2.5K, 5K, 10K,
16K Hz
40, 80, 160, 315, 630,
1.25K, 2.5K, 5K, 10K,
16K Hz
Range ±12 dB ±12 dB ±12 dB ±12 dB
Noise: 20Hz to 20KHz
bandwidth, IHF-A
weighted, line inputs
to main L/R outputs,
all channels assigned,
panned L/R
Master output, all fader
down
<-78 dBu <-78 dBu <-78 dBu <-78 dBu
Power amp output, all
fader down
<-63 dBu <-63 dBu <-63 dBu <-63 dBu
THD
Power output, 1KHz,
20Hz to 20KHz
@60 Watts, 4 ohms
<0.5%
@110 Watts, 4 ohms
<0.5%
@125 Watts, 4 ohms
<0.5%
@187.5 Watts, 4 ohms
<0.5%
Any output, 1KHz @
+14dBu, 20Hz to 20KHz,
channel inputs
<0.3% <0.3% <0.3% <0.3%
CMRR (1 KHz @ -60dBu,
Gain at maximum)
80 dB 80 dB 80 dB 80 dB
Crosstalk (1KHz @
0dBu, 20Hz to 20KHz
bandwidth, channel in
to main L/R outputs)
Channel fader down,
other channels at unity
<-63 dB <-63 dB <-63 dB <-63 dB
Channel muted, other
channels at unity
<-64 dB <-64 dB <-64 dB <-64 dB
Frequency Response
(Mic input to output)
20Hz ~ 20KHz, line level
o/p @ +4dBu into 600
ohms
+0/-2 dB +0/-2 dB +0/-2 dB +0/-2 dB
20Hz ~ 20KHz, power
amp o/p 1 watt into 8
ohms
+0/-2 dB +0/-2 dB +0/-2 dB +0/-2 dB
Maximum Level
Mic preamp input +10 dBu +10 dBu +10 dBu +10 dBu
All other inputs +22 dBu +22 dBu +22 dBu +22 dBu
Unbalanced output +22 dBu +22 dBu +22 dBu +22 dBu
Impedance
Lo-Z input (Mic in) 2.2K ohms 2.2K ohms 2.2K ohms 2.2K ohms
Hi-Z input (Line in) 5K ohms 5K ohms 5K ohms 5K ohms
Super Hi-Z (Line in) 470K ohms 470K ohms 470K ohms 470K ohms
All other input >10K ohms >10K ohms >10K ohms >10K ohms
RCA 2T output 1.2K ohms 1.2K ohms 1.2K ohms 1.2K ohms
All other outputs 560 ohms 560 ohms 560 ohms 560 ohms
Equalization 3-band, ±15 dB 3-band, ±15dB 3-band, ±15dB 3-band, ±15dB
Low EQ 80 Hz 80 Hz 80 Hz 80 Hz
