page 21
PHONIC CORPORATION POWERPOD User's Manual
DIMENSIONS
POWERPOD 620 POWERPOD 740 POWERPOD 1060 POWERPOD 1062
A 440 mm (17.3 inches) 471 mm (18.5 inches) 471 mm (18.5 inches) 471 mm (18.5 inches)
B 245 mm (9.6 inches) 265 mm (10.4 inches) 285 mm (11.2 inches) 285 mm (11.2 inches)
C 275 mm (10.8 inches) 275 mm (10.8 inches) 275 mm (10.8 inches) 275 mm (10.8 inches)
WEIGHT
POWERPOD 620 12.5 kg (27.5 lbs)
POWERPOD 740 13.5 kg (29.7 lbs)
POWERPOD 1060 14 kg (30.8 lbs)
POWERPOD 1062 14 kg (30.8 lbs)
