Phonic XP 2000 - Power Amplifier PCB Parts

Ref. Phonic Part No. Specifications
R281 003-10071-602-0 CEMENT RES. 10 J 2W P
R316 003-22071-602-0 CEMENT RES. 22 J 2W
R241.243.245.246.248.250.252.
253
003-22093-602-0 CEMENT RES. 0.22 J 5W
R240.247 006-10003-420-0 MF RES. 100F 0.5W M
R234.236.238.239.254.256.258.
259
006-10072-420-0 MF RES. 10F 0.25W M
R272 006-27023-420-0 MF RES.27K F 0.5W M
R269.280 006-33023-420-0 MF RES.33K F 0.5W M
R215.218 006-47083-420-0 MF RES. 4.7 F 0.5W M
R231.232.233.261.262.263 006-51072-420-0 MF RES. 51F 0.25W M
NTC4 011-10020-001-0 THERMISTER
NSA05C310-301
SVR201 020-47138-000-6 T/VR 470J T-085C-B470
0.5W
C212.217 030-47695-000-0 E/C 47MF K 160V P
L301 075-10082-100-0 INDUCTANCE 1UH K M
RA2 076-02411-001-0 RELAY T9AS1D12-24
(02182)
D204.205.302.305.306 090-00007-020-0 DIODE IN4004 SILTEK T
D214.215 090-00016-000-0 DIODE 1N5404
D207-210.219.220 090-02004-000-0 DIODE 1N4935 T
D211.213.216.218.221.222 090-02007-000-0 DIODE FR602
Q205.221 120-00005-000-0 TRAN MJE340
MOTOROLA
Q215.217.219.220 120-00008-600-0 TRAN 2SC5200-O
TOSHIBA
Q203.301 120-00008-800-0 TRAN MJE802
MOTOROLA
Q209 120-00009-500-0 TRAN 2SC4793-M
TOSHIBA
Q222.224.226.227 121-00006-000-0 TRAN 2SA1943-O
TOSHIBA
Q202.316 121-00006-100-0 TRAN MJE350
MOTOROLA
POWER AMPLIFIER PCB-PART SCHEMATIC
POWER AMPLIFIER PCB-PART SCHEMATIC
PHONIC CORPORATION
Page 10
XP2000/2000(B) SERVICE MANUAL
