POWER SUPPLY PCB-PART LIST
POWER SUPPLY PCB-PART LIST
Ref. Phonic Part No. Specifications
R3 005-10127-100-0 MOF RES. 100OHM 2W P
R4.5.6.7 006-33023-420-0 MF RES.33K F 0.5W M
R145.145A.145B 006-56003-420-0 MF RES. 560 F 0.5W M
NTC1.2.3 012-400B0-000-0 NTC THERMISTORS
N15SP004
C9.10 030-22848-002-0 E/C 2200MF Z 35V 16*27 P
C3.4.5.6 030-33896-000-0 E/C 3300UF 160V M 35*65
C7.8 030-47888-032-6 E/C 4700UF M 100V 30*63
105 C
C1 058-68325-100-0 MEX-683K 0.068MF/250V
18*13.5 P=15
RA1 076-02411-001-0 RELAY T9AS1D12-24
(02182)
D1.2.3.4.5 090-00007-020-0 DIODE IN4004 SILTEK T
BD3 090-10000-000-0 B/DIODE PB154
BD1.2 090-10016-000-0 B/DIODE KBPC5006
LED2 100-00110-000-0 LED BL-R5132N RED
LED1 100-00150-020-0 LED LG5120 GRN
LED3-11 100-00240-020-0 LED 5*5mm YLW
Q1.2 120-00005-000-0 TRAN MJE340
MOTOROLA
IC2 160-00002-909-0 IC 7915
IC1 160-00005-909-0 IC 7815
SW1.2.3.4 210-60001-000-0 SLD/SW SLD-43-10
CN1 211-09142-000-0
14P B.E./S 180
CN2 211-09202-000-0
20P B.E./S 180
CN8 211-10041-140-0 4P WAFER/S 2532-04
T1 211-10084-020-0 8P WAFER/S 396108 180
P=3.96MM
SPK-GND 212-10010-700-0 1P WAFER/P 200MM
UL1015#14 BLK
SPK-GND 212-10010-710-0 1P WAFER/P 250MM
UL1015#14 BWN
JP5 212-10032-480-0 3P WAFER/P 520MM
(PITCH=2.5MM)
