PHONIC CORPORATION
Page 18
XP2000/2000(B) SERVICE MANUAL
POWER AMPLIFIER PCB-PART SCHEMATICPOWER SUPPLY PCB-PART LIST
POWER SUPPLY PCB-PART LIST
J2 212-10032-480-6 3P WAFER/P 520MM
JP4 212-10032-490-0 3P WAFER/P 440MM
J1 212-10032-490-6 3P WAFER/P 440MM
JP8 212-10041-220-0 4P WAFER/P 500MM
JP9A 212-10090-440-0 9P WAFER/P 250MM
UL1015#16
PITCH=3.96MM
JP9B 212-10090-450-0 9P WAFER/P 350MM
UL1015#16
PITCH=3.96MM
FUSE1*2.FUSE2*2 281-00000-020-0 FUSE CLIP FH-1206
FIX IC1.2 313-00000-060-0 RUBBER WASHER
TO-2203
FIX IC1.2 314-00000-050-0
BUSHES 602S(V.0) 180
P1-10 315-00012-000-0 LUG PIN JP-15
IC1.2 526-20040-010-0 U HEAT.SINK POD1860
20*18
KBPC5006 526-20046-011-0 HEAT SINK XP3000
36.5*56.2*40
KBPC5006 590-24020-200-0 M/E BID SCR. M4*20 BLK
590-53010-100-0 M/E SET SCR. M3.0*10 NI
600-00302-010-0 HEX. NUT M3.0*2.0 NI
610-60300-700-0 PAN SPR WAS.
D3.0*6.0*0.7ZN
610-60401-001-0 PAN SPR. WAS. D4*7.6*1.0
NI
LED1.2 615-10054-620-0 LED BOSS L=6MM
R143.144 006-10012-420-0 MF RES. 1K F 0.25W M
R2 006-10022-420-0 MF RES. 10K F 0.25W M
R116.137 006-33011-400-0 MF RES. 3K3 F 0.125W T
R146 006-33022-420-0 MF RES. 33K F 0.25W M
R1 006-47032-420-0 MF RES. 470K F 0.25W M
C11.12 030-10656-0A0-0 E/C 10MF M 50V 5*11 T
C108.119 030-22628-0A0-0 E/C 22MF Z 16V 5*11 T
C2 030-47558-0A0-0 E/C 4.7MF Z 50V 5*11 T
290-34640-205-0 XP3000 C+G PWR+LED
PCB
Ref. Phonic Part No. Specifications
J1.2 382-20002-510-0 TINNER WIRE 2.5MM D0.6
