Phonic XP 2000 - Page 12

Ref. Phonic Part No. Specifications
R308.327.334 006-10032-420-0 MF RES. 100K F 0.25W M
R207 006-10072-420-0 MF RES. 10F 0.25W M
R330 006-12022-420-0 MF RES. 12K F 0.25W M
R341 006-15012-420-0 MF RES. 1K5 F 0.25W M
R274 006-18022-420-0 MF RES. 18K F 0.25W M
R222.224.228.229.307.323.335 006-22012-420-0 MF RES. 2K2 F 0.25W M
R325.336.337.340 006-22022-420-0 MF RES. 22K F 0.25W M
R320.321.322 006-22032-420-0 MF RES. 220K F 0.25W M
R225.226 006-24022-440-0 MF RES. 24K F 0.25W T
R275 006-27032-420-0 MF RES. 270K F 0.25W M
R223.227 006-30012-440-0 MF RES. 3K F 0.25W T
R.273 006-30022-420-0 MF RES. 30K F 0.25W M
R266 006-33002-420-0 MF RES. 330 F 0.25W M
R328 006-33012-410-0 MF RES. 3K3 F 0.25W P
R268.342 006-33022-420-0 MF RES. 33K F 0.25W M
R205.206.317.318 006-39012-420-0 MF RES. 3K9 F 0.25W M
R271 006-47012-420-0 MF RES. 4K7 F 0.25W M
R201 006-49912-420-0 MF RES. 4K99 F 0.25W M
R264.277.278 006-51072-420-0 MF RES. 51F 0.25W M
R301 006-56002-420-0 MF RES. 560 F 0.25W M
R329 006-56022-420-0 MF RES. 56K F 0.25W M
R303 006-62022-420-0 MF RES. 62K F 0.25W M
R270.319 006-68012-420-0 MF RES. 6K8 F 0.25W M
R209.210.333 006-68022-420-0 MF RES. 68K F 0.25W M
R301 006-75002-420-0 MF RES.750 F 0.25W M
R202 006-75022-420-0 MF RES. 75K F 0.25W T
C309 030-10558-0A0-0 E/C 1MF Z 50V 5*11 T
C301 030-10638-0A0-0 E/C 10MF Z 25V 5*11 T
C201.203.210 030-10656-0A0-0 E/C 10MF M 50V 5*11 T
C219.226.308 030-10728-0A0-0 E/C 100MF Z 16V 6*11 T
C310.311.312 030-22638-0A0-0 E/C 22MF Z 25V 5*11 T
C306 030-22728-0A0-0 E/C 220MF Z 16V 8*11 T
C313.314 030-47638-0A0-0 E/C 47MF Z 25V 6*11 T
C205 032-10636-0A0-0 NP E/C 10MF M 25V 6.3*11
T
C302 032-22586-0A0-0 NP E/C 2.2MF M 100V 6*11
T
POWER AMPLIFIER PCB-PART SCHEMATIC
POWER AMPLIFIER PCB-PART SCHEMATIC
Page 12
XP2000/2000(B) SERVICE MANUAL
PHONIC CORPORATION
