Phonic XP 2000 - Page 24

Ref. Phonic Part No. Specifications
IC1-6 160-00021-300-0 IC NJM2068 SMD JRC
290-34640-304-0 PIII2000/2000B/3000/3000
B D+E+F PCB
R312A.312B.313A.313B.314A.3
14B
006-10012-420-0 MF RES. 1K F 0.25W M
R153 006-10073-420-0 MF RES. 10F 0.5W M
C145 030-10484-000-0 E/C 0.1MF J 100V 5
C109.120.123.134 030-22628-0A0-0 E/C 22MF Z 16V 5*11 T
C109.120 030-22628-000-0 E/C 22MF Z 16V 5*11 P
C111 .1 22 030-47628-0A0-0 E/C 47MF Z 16V 5*11 T
Q303A.303B.304A.304B.305A.
305B
120-00000-800-0 TRAN. 2SC1815 GR
TOSHIBA
Ch1 / Ch2 CONTROL PCB-PART LIST
PHONIC CORPORATION
Page 24
XP2000/2000(B) SERVICE MANUAL
Ch1 / Ch2 CONTROL PCB-PART LIST
