Ref. Phonic Part No. Specifications
FIX TOP COV&PANEL*4 590-03006-200-0 M/E FLT SCR. M3.0*6 BLK
FIX BOT COV X'MER FIXED 590-03010-200-0 M/E FLT SCR. M3.0*10BLK
FIXED NEURIK*4 590-03012-200-0 M/E FLT SCR. M3.0*12
BLK D=5.6mm
FIX PANEL & HANDLE 590-04008-100-0 M/E FLT SCR. M4.0*8 NI
FIX VR PCB&PANEL*4 FIX
PWR PCB&BOT COVER
590-33008-200-0 M/E RUD SCR. M3.0*8 BLK
FIX PANEL&HEADLE*6 590-44008-200-0 M/E PAN SCR. M4.0*8 BLK
GND SCREW FIX BOT COV
HEAT SINK*12
590-44010-200-0 M/E PAN SCR. M4*10 BLK
FIX FAN&HEATSINK*4 590-44040-200-0 M/E PAN SCR.M4.0*40BLK
BACK PANEL&PANEL 590-53006-200-0 M/E SET SCR. M3.0*6 BLK
FIX FAN BRACKET 590-53012-200-0 M/E SET SCR.
M3.0*12 BLK
590-54006-200-0 M/E SET SCR. M4*6 BLK
XLR/JACK 591-03008-200-0 T/P FLT SCR. D3.0*8 BLK
591-54010-200-0 T/P SET SCR. D4.0*10 BLK
FIX FAN BRACKET FIX XLR*4 600-00302-210-0 HEX. NUT M3.0*2.2 NI
600-00302-220-0 NEX NUT M3.0*2.2
GND 600-00403-510-0 HEX. NUT M4.0*3.5 NI
GND 600-00602-010-0 HEX. NUT M6.0*2.0 NI
610-00300-516-0 FIBER WAS. D3*D8*0.5
RED
HEAT SINK 610-00402-018-0 FIBER WAS D4.0*D9. 0*2.0
RED
FAN NET 610-00408-001-0 PLA. WAS. D4.0*8.0*1.0 NI
PHONE XLR/JACK 610-20901-001-0 TOOTH WAS D9*12*1 NI
POWER PCB 610-30300-501-0 TOOTH WAS.
D3.0*D6.5*0.5 NI
GND 610-30400-501-0 TOOTH WAS.
D4.0*D8.5*0.5 NI
FAN BRACKET 610-60300-700-0 PAN SPR WAS.
D3.0*6.0*0.7ZN
BOT COV&HEAT SINK 610-60401-001-0 PAN SPR. WAS.
D4*7.6*1.0 NI
GND 615-10001-130-0 EARTH BOSS 2+5 NI
GND 615-10002-130-0 EARTH BOSS 10+5 NI
MISCELLANOUS ITEMS
MISCELLANOUS ITEMS
PHONIC CORPORATION
Page 27
XP2000/2000(B) SERVICE MANUAL
