INSTRUCTION MANUAL
ashes, replace the batteries.
Note
：
If the Ares II is powered on and
left idle for one hour, it will automatically
power o.
Test button
1. Press the test button on the transmitter
and
any ash/ studio light connected to
the Ares II receivers set to the same channel,
group and Digital ID will trigger
.
2. Press the test button
on the receiver
to re the ash/studio light connected to the
receiver.
LED status light
1. When the transmitter and receiver are
powered on and idle
，
the LED status light
will ash green
.
2. When transmitter is sending commands or
the receiver is receiving commands, the LED
status light will light red.
Connecting the Ares II
Transmitter to the camera
hot shoe
1. Switch o camera and transmitter.
2.
Connect the transmitter to camera hot shoe.
