INSTRUCTION MANUAL
1. Turn o the ash/strobe and the Phottix
Odin receiver.
2. Connect a cable to the receiver’ s 3.5 mm
Output Port.
3. Connect the opposite end of the cable to a
ash or studio strobe (A 6.3 mm adapter is
included for studio strobes).
4. Turn on the ash/strobe and the Phottix
Odin receiver.
5. Set the ash to Manual mode – no TTL func-
tions can be used when a compatible ash is
triggered by cable.
Connecting the Odin receiver to
studio lights or ashes by cable
13
