The TCU has two main function screens:
TTL/Mixed Function Screen and Ratio.
TTL/Mixed allows groups A, B and C to be set
to TTL, Manual or OFF individually with adjust-
ments to Zoom, EV level or power level.
Ratio allows groups A and B can be set from 8:1
to 1:8. EV levels can also be adjusted from -3 to
+3 (similar to the Sony ADI TTL system avail-
able on some ashes).
Functions
Press the Option button on the TCU. The
Option Button will switch between TTL/Mixed
screen and Ratio screen.
To change function screens
The Selection Button allows you to cycle
through groups A, B, and C, and Channel selec-
tions. Active selections will ash on the LCD.
1. The - / + buttons will change the EV adjust-
ments or Power Level while groups A, B or C
are selected.
2. The - / + buttons will change the transmis-
sion channel (1, 2, 3 or 4) when Channel is
selected. This will change the channel the TCU
uses to transmit.
TTL/Mixed Functions Screen
While groups A, B or C are selected, pressing
the Mode button will change from TTL, (M)
Manual, or O functions.
TTL: Will re ashes using TTL metering. The
TTL / M / O
8
5. Turn on the camera.
