see the flow in the integral meter.
The analyzer automatically reads the oxygen level and scales the
display so that it always reads on an appropriate range.You don't need
to select a range. The voltage output and the data storage use a preset
range (normally 0-100ppm) but that can be changed with the PC
interface program.
When you turn on the analyzer, the data storage function is always off.
If you wish to store data you have to manually turn it on by pressing
and holding the "Confirm/Save" button for about 3 seconds. At the
same time on the bottom of the screen, you can see the the figure" "
flash, indicating the data will be kept.
3.2 Using the analyzer
Although the instrument has a strong and robuts structure, one should
still be gentle and take care when operating. Please avoid exposure to
the rain and rapid temperature changes. For example, during operation
