-10-
PKI-0041-5-E
Forlampinstallation,aholewithadiameterof
8mmisrequired.Makenecessarypreparation
suchasinstallationoflampbracket.
【5】Lampinstallation
● Whenusingacommerciallysuppliedlampbracket,beforeremovingtheboltthatisalreadyinstalled
onthecarbody,makesurethatitissafetodoso.
● Thelampshouldbemountedinanareasufficienttosupportitssizeandweight.
Failuretodosomayresultinexcessvibrationleadingtoshorterlifeandorphysicaldamageto
thelamporyourvehicle.
● Donotattempttoinstallthelampdirectlytoanyplasticpartofthecarbody.
Ifthelampneedstobeinstalledontheplasticreinforcementmaterialsshouldbeplacedonboth
sidesoftheplasticpart.
● Wheninstalling,makesurethelampbody,lensandrimarenottouchingthebumperandotherplastic
parts.Suchplasticpartsmightdeform.
● Thelampinstallationsurfaceshouldbeflat.
● Thelampshouldbetightenedtothedegreethatthelampbodycannotbemovedbyhand.
● Thelampsaredesignedtobemountedupright.ItisveryimportantthatyoumakesurethatthePIAA
 etchedinthelensreadsrightsideup.
Hexnut
(L/M8)(Item ⑱ )
Tighteningtorque：11ft・Ibs(15N・m)
Hexagonsocket
headbuttonbolt
(L/M8)(Item ⑮ )
Washer(L/M8)
(Item ⑯ )
Springwasher
（L/M8）(Item ⑰ )
Hexagonal
wrench(M8)
(Item ㉙ )
