Piaa RF6 - Tools Required; Installation Preparations

-4-
PKI-0041-5-E
㉔ One-touch
 connector(1pc)
㉕ Wiretie
 (5pcs)
㉚Hexagonalwrench
 (M6)(1pc)
㉙Hexagonalwrench
 (M8)(1pc)
㉘Hexagonalwrench
 (M10)(1pc)
㉛Hexagonalwrench
 (M4)(1pc)
⑲Connectionbracket
 (1pc)
⑳Hexagonsocket
 headbolt (M4)(2pcs)
※Pleaseusethetoolsindicatedbelow.
● Pliers
ToolsRequired
● 17mmwrench ● 13mmwrench
【1】Installationpreparations
×２
Hexnut
(S/Item ⑧ )
Slider(Item ⑦ )
（１）CombinetheSlider(Item⑦ )andtheHexnut(S/Item⑧ )
asshowninthefigurebelow.
MountingmethodA
●IfinstallwiththeMountingmethodA
 onthevehicle,refertoP4〜 P8.
●IfinstallwiththeMountingmethodB
 onthevehicle,refertoP9〜P12.
㉒ Switch
(1pc)
㉖ Rubbercap
(2pcs)
㉗Dummyconnector
(1pc)
㉑ Pre-assembledrelayharness
withfuse【LR-39】（1set）
㉓Double-sticktape
 forswitch (1pc)
