Piaa RF6 - Mounting Method A: Lamp Installation

-6-
PKI-0041-5-E
● Whenusingacommerciallysuppliedlampbracket,beforeremovingtheboltthatisalreadyinstalled
onthecarbody,makesurethatitissafetodoso.
● Thelampshouldbemountedinanareasufficienttosupportitssizeandweight.
Failuretodosomayresultinexcessivevibrationleadingtoshorterbulblifeandorphysicaldamage
 tothelamporyourvehicle.
● Donotattempttoinstallthelampdirectlytoanyplasticpartofthecarbody.
● Wheninstalling,makesurethelampbody,lensandrimarenottouchingthebumperandotherplastic
parts.Suchplasticpartsmightdeform.
● Thelampinstallationsurfaceshouldbeflat.
● Thelampshouldbetightenedtothedegreethatthelampbodycannotbemovedbyhand.
● Thelampsaredesignedtobemountedupright.ItisveryimportantthatyoumakesurethatthePIAA
 etchedinthelensreadsrightsideup.
Forlampinstallation,aholewithadiameterof
10mmisrequired.Makenecessarypreparation
suchasinstallationoflampbracket.
Hexnut
(L/Item ④ )
【2】Lampinstallation
Rubbercushion
(Item ⑤ )
Tighteningtorque：18ft・Ibs(24N・m)
Sidecap
(Item ⑨ )
Sidecap
(Item ⑨ )
