-7-
PKI-0041-5-E
【3】Beforestartingtheworkprocedures...
ByusingtheConnectionbracket(Item ⑲ )2mainlampunits(Item ① )canbeconnected.
Wheninstallingandusingthemainlampunit,followthe■Lampconnectionproceduresindicatedbelow.
Ifnotinstallingthemainlampunitusingthisprocedurecontinueontopage4,【1】Installationpreparations
andfollowtheinstructionsindicatedthere.Inaddition,ifnotconnectingthelamps,theconnectionbrackets
(Item ⑲ )andthe Hexagon socketheadbolt(M4/Item ⑳ )will notbeused.Therefore,pleasestorethem
properlyforsafekeeping.
InstalltheConnectionbracket(Item⑲ )tothenutonthelampmainunitasshowninthefigure.Usethe
Hexagonsocketheadbolt(M4/Item⑳ )tosecureitfirmlyinplace.
Lampmainunit(Item①）
Nutsections
Connectionbracket
（Item ⑲）
Hexagonsocket
headbolt(M4)
(Item⑳）
Hexagonalwrench(M4)
(Item ㉛ )
Tighteningtorque：2.2ft・Ibs(3N・m)
※Thefollowingworkproceduresshownbelowareforthe
"RF6"modelbutthesameprocedurescanalsobeused
forunits"RF10"and"RF18".
■Lampconnectionprocedures
