Piaa RF6 - Mounting Method A: Multi-Lamp Cautions; Bracket Configuration

-8-
PKI-0041-5-E
●UsetherecommendedtorqueandapplyequalforcewhentighteningtheHexagonsocketheadbolt
(M4/Item⑳ ).
●Ifconnecting3lampsinarow,makesuretoinstalltherightnumberofbracket(s)foreachsizefalamp.
●WhenconnectinglampunitsRF6andRF10,werecommendthat2InstallationbracketsA(Item② )
beusedoneachlampunit.
IfthereisaproblemwiththeinstallationpositionandonlyoneInstallationbracketAcanbeinstalledon
eachlamp,installitontheouterholefromcenter.
●WheninstallingandusingRF18unit,makesuretoinstall2InstallationbracketsA(Item② )at
 2positionsoneachlamp.
Afterinstallingthelamp,followtheP13 【7】 RelayHarnessInstallationSequence.
InstallationbracketA
Center
Center
Center
Center
Center
Center
