03_16
5.Working from the right side of the vehicle, unscrew the two indicated screws and
remove the plastic cover.
03_17
6.Remove the clamp to allow the removal of the cap to check for the presence of oil
due to condensation of vapours.
REMOVE ANY DEPOSIT THAT MAY HAVE FORMED IN THE BLEED PIPE, COM-
ING FROM THE FILTER BOX. PROCEED AS FOLLOWS:
1. remove the cap;
2. discharge the contents into a container and send it to a recycling bank.
03_18
Cooling fluid level (03_18, 03_19, 03_20, 03_21)
Engine cooling is carried out by a forced-circulation coolant system. The coolant con-
sists of a mixture 50% de-ionised water and 50% glycol ethylene-based antifreeze
solution with corrosion inhibitors. The coolant supplied with the scooter is already
mixed and ready for use.
For the proper functioning of the engine, it is necessary for the coolant temperature
to be maintained at about 90 ° C. If the needle of the gauge enters the red zone, stop
the engine, let it cool down and check the coolant level; if the level is OK, contact an
Authorised Service Centre.
49
