Protected circuits: (for vehicles
with rear suspension control)
battery-powered: voltage
regulator, electrical fan, electronic
ignition.
live: Run/Off, starter, TPS,
electronic ignition, fuel pump if
available, fuse 5.
Capacity: 15A
Protected circuits: (for vehicles
with front suspension control)
battery-powered: voltage
regulator, electrical fan, electronic
ignition, TPS.
live: starter, electronic ignition, fuel
pump if available, fuses 4-8.
Location: battery compartment
Fuse No. 3 Capacity: 20A
Protected circuits: (for vehicles
with rear suspension control)
battery-powered: parking control
ECU
Capacity: 15 A
Protected circuits: (for vehicles
without front suspension
control) battery-powered: light
relay.
Location:battery compartment
Fuse No. 4 Capacity: 4A
64
