PIAGGIO X10 500ie Executive 2012 User Manual

Quantity: 2
Power: -
Front light group
To replace the front headlight assembly bulbs, contact an Authorised Service Cen-
tre.
Headlight adjustment (03_31, 03_32, 03_33, 03_34, 03_35,
03_36, 03_37, 03_38)
To adjust the front headlight, remove the front cover of the vehicle.
FRONT COVER REMOVAL
03_31
Using a screwdriver and paying attention to the bodywork, remove the Piaggio clip-
on badge «A».
88
3 Maintenance

PIAGGIO X10 500ie Executive 2012 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	493 cc
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
ABS	Yes
Front Tire	120/70-15
Rear Tire	150/70-14
Seat Height	760 mm
Fuel Capacity	15.5 liters
Width	800 mm
Top Speed	160 km/h
Power	40 hp @ 7, 250 rpm
Cooling System	Liquid cooled
Transmission	CVT
Front Brake	Dual 280 mm discs
Rear Brake	240 mm disc
Length	2, 260 mm
Wheelbase	1625 mm
Rear Suspension	Dual hydraulic shocks
