BESIDES, IF AFTER REPLACING A FUSE, THE NEW FUSE ALSO BLOWS, THE
SCOOTER NEEDS TO BE TAKEN TO AN AUTHORISED PIAGGIO/GILERA SERV-
ICE CENTRE TO IDENTIFY THE CAUSE OF THE FAULT AND AVOID FURTHER
DAMAGE TO THE ELECTRIC SYSTEM COMPONENTS OR THE VEHICLE IT-
SELF.
CAUTION
MODIFICATIONS OR REPAIRS TO THE ELECTRICAL SYSTEM, PERFORMED
INCORRECTLY OR WITHOUT STRICT ATTENTION TO THE TECHNICAL SPEC-
IFICATIONS OF THE SYSTEM, CAN CAUSE ERRORS IN FUNCTIONING AND
RISK OF FIRE.
FUSE TABLE
Fuse No. 1 Threshold of operation: 30 A
Location: Battery compartment on
the left side
Protected circuits: Battery
charge
Fuse No. 2 Threshold of operation: 15A
Location: Battery compartment on
the left side
Protected circuits: Lines
protected by fuses 8, 9, 10,12 -
Engine stop remote control
60
