Fuse No. 3 Threshold of operation: 15A
Location: Battery compartment on
the left side
Protected circuits: 12V 180W
socket - Wiring for anti-theft device
- Electrical fan remote control -
Saddle opening control unit -
Actuator for opening saddle and
glove-box
Fuse No. 4 Threshold of operation: 10 A
Location: Battery compartment on
the left side
Protected circuits: Remote
control for injection components
(fuel pump, injector, h.v. coil.)
Fuse No. 5 Threshold of operation: 10 A
Location: Battery compartment on
the left side
Protected circuits: Headlight
remote control - Bulb for helmet
compartment light - Warning light
for saddle/rear compartment cover
open
Fuse No. 6 Threshold of operation: 3 A
Location: Battery compartment on
the left side
Protected circuits: Ignition ECU -
Immobilizer decoder
61
