03_24
Rear-viewmirrors (03_24)
To adjust the stem position, lift the rubber protection and loosen the nut «A» with an
open wrench (opening 13 mm); adjust the stem to the best position and tighten the
screw.
03_25
Idleadjustment (03_25)
To adjust the idle speed it is necessary to actuate the screw «D» located in the car-
burettor. It is necessary to actuate on both set screws«E» to adjust the clearance of
the throttle control transmission. Adjust the idle speed with the rear wheel off the
ground (vehicle on stand) and with a warm engine: screw and unscrew the knob-type
head screw until reaching a regular rpm: i.e, without letting the engine move the rear
wheel.
This operation should be carried out at an Authorised PIAGGIO Service Centre.
SHOULD THERE BE PROBLEMS DURING THE IDLE SPEED ADJUSTMENT OP-
ERATION, IT MAY BE NECESSARY TO ADJUST THE LEVEL OF EXHAUST
EMISSIONS (CO). TURN TO AN AUTHORISED PIAGGIO SERVICE CENTRE TO
CARRY OUT THESE OPERATIONS.
41
