PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 1 - TECHNICAL SPECIFICATION
Programmable Resistor – 40-295/296
pickeringtest.com
Specifications
Power Requirements
+3.3V +5V +12V -12V
0 1.85A (typ 450mA) 0 0
Mechanical Characteristics
Single slot 3U PXI (CompactPCI card).
Module weight: 200g (40-295-021-3/24)
240g (40-295-021-10/8)
340g (40-295-121-10/16)
3D models for all versions in a variety of popular le formats are
available on request.
Connectors
PXI bus via 32-bit P1/J1 backplane connector.
Resistor channel signals via front panel 37-pin male D-Type
connector.
Relay Type
The 40-295/296 is tted with Reed Relays (Sputtered Ruthenium
type), these offer very long life with good low level switching
performance and excellent contact resistance stability.
All reed relays are manufactured by our sister company Pickering
Electronics: pickeringrelay.com
Programmable Resistor Specification
Max Switch Voltage: 100V*
Resolution 1Ω
† Accuracy of Fitted Resistor: ±0.5% (0 to 1MΩ)
±1% (>1MΩ)
Residual Resistance, typical:
(when chain resistance is set
to 0Ω)
1Ω (8-bit)
1.5Ω (12-bit)
2Ω (16-bit)
3Ω (24-bit)
Max Power:
Max Switch Current:
Max Carry Current:
0.5W
0.5A
1.0A
Operate Time:
Release Time:
<0.5ms
<0.5ms
Expected Life
Low power load:
Full power load:
>1x10
8
operations
>1x10
6
operations
* For full voltage rating, signal sources must be fully isolated from
mains supply and safety earth.
† Overall accuracy of module is a combination of the tted resistor
accuracy and the relay/track resistance that makes up the residual
path resistance.
Operating/Storage Conditions
Operating Conditions
Operating Temperature:
Humidity:
Altitude:
0°C to +55°C
Up to 90% non-condensing
5000m
Storage and Transport Conditions
Storage Temperature:
Humidity:
Altitude:
-20°C to +75°C
Up to 90% non-condensing
15000m
PXI & CompactPCI Compliance
The module is compliant with the PXI Specication 2.2. Local Bus,
Trigger Bus and Star Trigger are not implemented.
Uses a 33MHz 32-bit backplane interface.
Safety & CE Compliance
All modules are fully CE compliant and meet applicable EU
directives: Low-voltage safety EN61010-1:2010, EMC Immunity
EN61326-1:2013, Emissions EN55011:2009+A1:2010.
