Page 1.4
PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 1 - TECHNICAL SPECIFICATION
Programmable Resistor – 40-295/296
pickeringtest.com
Ordering Information
Mating Connectors & Cabling
For connection accessories for the 40-295/296 series please
refer to the 90-007D 37-pin D-Type Connector Accessories data
sheet where a complete list and documentation can be found for
accessories, or refer to the Connection Solutions catalog.
Resistor Module Order Codes
10 x 8 Bit (0Ω to 255Ω)
18 x 8 Bit (0Ω to 255Ω)
40-295-021-10/8
40-295-121-18/8
5 x 12 Bit (0Ω to 4kΩ)
10 x 12 Bit (0Ω to 4kΩ)
40-295-021-5/12
40-295-121-10/12
5 x 16 Bit (0Ω to 65kΩ)
10 x 16 Bit (0Ω to 65kΩ)
40-295-021-5/16
40-295-121-10/16
3 x 24 Bit (0Ω to 16MΩ)
6 x 24 Bit (0Ω to 16MΩ)
40-295-021-3/24
40-295-121-6/24
Potentiometer Module Order Codes
5 x 8 Bit Pot (0Ω to 255Ω Wiper)
9 x 8 Bit Pot (0Ω to 255Ω Wiper)
40-296-021-5/8
40-296-121-9/8
2 x 12 Bit Pot (0Ω to 4kΩ Wiper)
4 x 12 Bit Pot (0Ω to 4kΩ Wiper)
40-296-021-2/12
40-296-121-4/12
2 x 16 Bit Pot (0Ω to 65kΩ Wiper)
4 x 16 Bit Pot (0Ω to 65kΩ Wiper)
40-296-021-2/16
40-296-121-4/16
1 x 24 Bit Pot (0Ω to 16MΩ Wiper)
3x 24 Bit Pot (0Ω to 16MΩ Wiper)
40-296-021-1/24
40-296-121-3/24
Other Resistor Modules
Pickering Interfaces manufacture a range of variable resistor
modules in the PXI format. If you have a requirement for a variable
resistor module please contact your local sales ofce with the
information below and we will advise you on the best solution for
your application.
Lowest Resistance †
Highest Resistance
Resistance Resolution
Overall Accuracy
Maximum Power/Current
Number of Channels (variable resistors)
† Resistance is as measured across the user connector terminals,
minimum resistance must have a non-zero value.
Product Customization
Pickering PXI modules are designed and manufactured on our own
exible manufacturing lines, giving complete product control and
enabling simple customization to meet very specic requirements.
Customization can include:
• Alternative resistance range
• Alternative resolution
• Different number of channels
• Different performance specications
All customized products are given a unique part number, fully
documented and may be ordered at any time in the future. Please
contact your local sales ofce to discuss.
