Page 4.5
PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 4 - PROGRAMMING GUIDE
Sub-
Unit
Bit
Channel/
Resistor
Resistor
Value
Relay
No.
Sub-
Unit
Bit
Channel/
Resistor
Resistor
Value
Relay
No.
Sub-
Unit
Bit
Channel/
Resistor
Resistor
Value
Relay
No.
1 1 1/A1 1Ω M-1 4 7 4/A7 64Ω M-55 7 13 7/B5 8Ω D-28
1 2 1/A2 2Ω M-2 4 8 4/A8 128Ω M-56 7 14 7/B6 4Ω D-27
1 3 1/A3 4Ω M-3 4 9 4/B1 128Ω M-64 7 15 7/B7 2Ω D-26
1 4 1/A4 8Ω M-4 4 10 4/B2 64Ω M-63 7 16 7/B8 1Ω D-25
1 5 1/A5 16Ω M-5 4 11 4/B3 32Ω M-62 8 1 8/A1 1Ω D-33
1 6 1/A6 32Ω M-6 4 12 4/B4 16Ω M-61 8 2 8/A2 2Ω D-34
1 7 1/A7 64Ω M-7 4 13 4/B5 8Ω M-60 8 3 8/A3 4Ω D-35
1 8 1/A8 128Ω M-8 4 14 4/B6 4Ω M-59 8 4 8/A4 8Ω D-36
1 9 1/B1 128Ω M-16 4 15 4/B7 2Ω M-58 8 5 8/A5 16Ω D-37
1 10 1/B2 64Ω M-15 4 16 4/B8 1Ω M-57 8 6 8/A6 32Ω D-38
1 11 1/B3 32Ω M-14 5 1 5/A1 1Ω M-65 8 7 8/A7 64Ω D-39
1 12 1/B4 16Ω M-13 5 2 5/A2 2Ω M-66 8 8 8/A8 128Ω D-40
1 13 1/B5 8Ω M-12 5 3 5/A3 4Ω M-67 8 9 8/B1 128Ω D-48
1 14 1/B6 4Ω M-11 5 4 5/A4 8Ω M-68 8 10 8/B2 64Ω D-47
1 15 1/B7 2Ω M-10 5 5 5/A5 16Ω M-69 8 11 8/B3 32Ω D-46
1 16 1/B8 1Ω M-9 5 6 5/A6 32Ω M-70 8 12 8/B4 16Ω D-45
2 1 2/A1 1Ω M-17 5 7 5/A7 64Ω M-71 8 13 8/B5 8Ω D-44
2 2 2/A2 2Ω M-18 5 8 5/A8 128Ω M-72 8 14 8/B6 4Ω D-43
2 3 2/A3 4Ω M-19 5 9 5/B1 128Ω M-80 8 15 8/B7 2Ω D-42
2 4 2/A4 8Ω M-20 5 10 5/B2 64Ω M-79 8 16 8/B8 1Ω D-41
2 5 2/A5 16Ω M-21 5 11 5/B3 32Ω M-78 9 1 9/A1 1Ω D-49
2 6 2/A6 32Ω M-22 5 12 5/B4 16Ω M-77 9 2 9/A2 2Ω D-50
2 7 2/A7 64Ω M-23 5 13 5/B5 8Ω M-76 9 3 9/A3 4Ω D-51
2 8 2/A8 128Ω M-24 5 14 5/B6 4Ω M-75 9 4 9/A4 8Ω D-52
2 9 2/B1 128Ω M-32 5 15 5/B7 2Ω M-74 9 5 9/A5 16Ω D-53
2 10 2/B2 64Ω M-31 5 16 5/B8 1Ω M-73 9 6 9/A6 32Ω D-54
2 11 2/B3 32Ω M-30 6 1 6/A1 1Ω D-1 9 7 9/A7 64Ω D-55
2 12 2/B4 16Ω M-29 6 2 6/A2 2Ω D-2 9 8 9/A8 128Ω D-56
2 13 2/B5 8Ω M-28 6 3 6/A3 4Ω D-3 9 9 9/B1 128Ω D-64
2 14 2/B6 4Ω M-27 6 4 6/A4 8Ω D-4 9 10 9/B2 64Ω D-63
2 15 2/B7 2Ω M-26 6 5 6/A5 16Ω D-5 9 11 9/B3 32Ω D-62
2 16 2/B8 1Ω M-25 6 6 6/A6 32Ω D-6 9 12 9/B4 16Ω D-61
3 1 3/A1 1Ω M-33 6 7 6/A7 64Ω D-7 9 13 9/B5 8Ω D-60
3 2 3/A2 2Ω M-34 6 8 6/A8 128Ω D-8 9 14 9/B6 4Ω D-59
3 3 3/A3 4Ω M-35 6 9 6/B1 128Ω D-16 9 15 9/B7 2Ω D-58
3 4 3/A4 8Ω M-36 6 10 6/B2 64Ω D-15 9 16 9/B8 1Ω D-57
3 5 3/A5 16Ω M-37 6 11 6/B3 32Ω D-14 ─ ─ Not Fitted D-65
3 6 3/A6 32Ω M-38 6 12 6/B4 16Ω D-13 ─ ─ Not Fitted D-66
3 7 3/A7 64Ω M-39 6 13 6/B5 8Ω D-12 ─ ─ Not Fitted D-67
3 8 3/A8 128Ω M-40 6 14 6/B6 4Ω D-11 ─ ─ Not Fitted D-68
3 9 3/B1 128Ω M-48 6 15 6/B7 2Ω D-10 ─ ─ Not Fitted D-69
3 10 3/B2 64Ω M-47 6 16 6/B8 1Ω D-9 ─ ─ Not Fitted D-70
3 11 3/B3 32Ω M-46 7 1 7/A1 1Ω D-17 ─ ─ Not Fitted D-71
3 12 3/B4 16Ω M-45 7 2 7/A2 2Ω D-18 ─ ─ Not Fitted D-72
3 13 3/B5 8Ω M-44 7 3 7/A3 4Ω D-19 ─ ─ Not Fitted D-80
3 14 3/B6 4Ω M-43 7 4 7/A4 8Ω D-20 ─ ─ Not Fitted D-79
3 15 3/B7 2Ω M-42 7 5 7/A5 16Ω D-21 ─ ─ Not Fitted D-78
3 16 3/B8 1Ω M-41 7 6 7/A6 32Ω D-22 ─ ─ Not Fitted D-77
4 1 4/A1 1Ω M-49 7 7 7/A7 64Ω D-23 ─ ─ Not Fitted D-76
4 2 4/A2 2Ω M-50 7 8 7/A8 128Ω D-24 ─ ─ Not Fitted D-75
4 3 4/A3 4Ω M-51 7 9 7/B1 128Ω D-32 ─ ─ Not Fitted D-74
4 4 4/A4 8Ω M-52 7 10 7/B2 64Ω D-31 ─ ─ Not Fitted D-73
4 5 4/A5 16Ω M-53 7 11 7/B3 32Ω D-30
4 6 4/A6 32Ω M-54 7 12 7/B4 16Ω D-29
Table 4.1 - 40-296 - 8-Bit Versions - Sub-Unit, Resistor & Relay Cross Reference
