Page 4.6
PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 4 - PROGRAMMING GUIDE
Table 4.2 - 40-296 - 12-Bit Versions - Sub-Unit, Resistor & Relay Cross Reference
Sub-
Unit
Bit
Channel/
Resistor
Resistor
Value
Relay
No.
Sub-
Unit
Bit
Channel/
Resistor
Resistor
Value
Relay
No.
Sub-
Unit
Bit
Channel/
Resistor
Resistor
Value
Relay
No.
1 1 1/A1 1Ω M-1 2 15 2/B3 512Ω M-58 ─ ─ Not Fitted D-29
1 2 1/A2 2Ω M-2 2 16 2/B4 256Ω M-57 ─ ─ Not Fitted D-30
1 3 1/A3 4Ω M-3 2 17 2/B5 128Ω M-56 ─ ─ Not Fitted D-31
1 4 1/A4 8Ω M-4 2 18 2/B6 64Ω M-55 ─ ─ Not Fitted D-32
1 5 1/A5 16Ω M-5 2 19 2/B7 32Ω M-54 ─ ─ Not Fitted D-48
1 6 1/A6 32Ω M-6 2 20 2/B8 16Ω M-53 ─ ─ Not Fitted D-47
1 7 1/A7 64Ω M-7 2 21 2/B9 8Ω M-52 ─ ─ Not Fitted D-46
1 8 1/A8 128Ω M-8 2 22 2/B10 4Ω M-51 ─ ─ Not Fitted D-45
1 9 1/A9 256Ω M-9 2 23 2/B11 2Ω M-50 4 13 4/B1 2048Ω D-44
1 10 1/A10 512Ω M-10 2 24 2/B12 1Ω M-49 4 14 4/B2 1024Ω D-43
1 11 1/A11 1024Ω M-11 3 1 3/A1 1Ω M-65 4 15 4/B3 512Ω D-42
1 12 1/A12 2048Ω M-12 3 2 3/A2 2Ω M-66 4 16 4/B4 256Ω D-41
─ ─ Not Fitted M-13 3 3 3/A3 4Ω M-67 4 17 4/B5 128Ω D-40
─ ─ Not Fitted M-14 3 4 3/A4 8Ω M-68 4 18 4/B6 64Ω D-39
─ ─ Not Fitted M-15 3 5 3/A5 16Ω M-69 4 19 4/B7 32Ω D-38
─ ─ Not Fitted M-16 3 6 3/A6 32Ω M-70 4 20 4/B8 16Ω D-37
─ ─ Not Fitted M-32 3 7 3/A7 64Ω M-71 4 21 4/B9 8Ω D-36
─ ─ Not Fitted M-31 3 8 3/A8 128Ω M-72 4 22 4/B10 4Ω D-35
─ ─ Not Fitted M-30 3 9 3/A9 256Ω M-73 4 23 4/B11 2Ω D-34
─ ─ Not Fitted M-29 3 10 3/A10 512Ω M-74 4 24 4/B12 1Ω D-33
1 13 1/B1 2048Ω M-28 3 11 3/A11 1024Ω M-75 ─ ─ Not Fitted D-49
1 14 1/B2 1024Ω M-27 3 12 3/A12 2048Ω M-76 ─ ─ Not Fitted D-50
1 15 1/B3 512Ω M-26 ─ ─ Not Fitted M-77 ─ ─ Not Fitted D-51
1 16 1/B4 256Ω M-25 ─ ─ Not Fitted M-78 ─ ─ Not Fitted D-52
1 17 1/B5 128Ω M-24 ─ ─ Not Fitted M-79 ─ ─ Not Fitted D-53
1 18 1/B6 64Ω M-23 ─ ─ Not Fitted M-80 ─ ─ Not Fitted D-54
1 19 1/B7 32Ω M-22 ─ ─ Not Fitted D-16 ─ ─ Not Fitted D-55
1 20 1/B8 16Ω M-21 ─ ─ Not Fitted D-15 ─ ─ Not Fitted D-56
1 21 1/B9 8Ω M-20 ─ ─ Not Fitted D-14 ─ ─ Not Fitted D-57
1 22 1/B10 4Ω M-19 ─ ─ Not Fitted D-13 ─ ─ Not Fitted D-58
1 23 1/B11 2Ω M-18 3 13 3/B1 2048Ω D-12 ─ ─ Not Fitted D-59
1 24 1/B12 1Ω M-17 3 14 3/B2 1024Ω D-11 ─ ─ Not Fitted D-60
2 1 2/A1 1Ω M-33 3 15 3/B3 512Ω D-10 ─ ─ Not Fitted D-80
2 2 2/A2 2Ω M-34 3 16 3/B4 256Ω D-9 ─ ─ Not Fitted D-79
2 3 2/A3 4Ω M-35 3 17 3/B5 128Ω D-8 ─ ─ Not Fitted D-78
2 4 2/A4 8Ω M-36 3 18 3/B6 64Ω D-7 ─ ─ Not Fitted D-77
2 5 2/A5 16Ω M-37 3 19 3/B7 32Ω D-6 ─ ─ Not Fitted D-76
2 6 2/A6 32Ω M-38 3 20 3/B8 16Ω D-5 ─ ─ Not Fitted D-75
2 7 2/A7 64Ω M-39 3 21 3/B9 8Ω D-4 ─ ─ Not Fitted D-74
2 8 2/A8 128Ω M-40 3 22 3/B10 4Ω D-3 ─ ─ Not Fitted D-73
2 9 2/A9 256Ω M-41 3 23 3/B11 2Ω D-2 ─ ─ Not Fitted D-72
2 10 2/A10 512Ω M-42 3 24 3/B12 1Ω D-1 ─ ─ Not Fitted D-71
2 11 2/A11 1024Ω M-43 4 1 4/A1 1Ω D-17 ─ ─ Not Fitted D-70
2 12 2/A12 2048Ω M-44 4 2 4/A2 2Ω D-18 ─ ─ Not Fitted D-69
─ ─ Not Fitted M-45 4 3 4/A3 4Ω D-19 ─ ─ Not Fitted D-68
─ ─ Not Fitted M-46 4 4 4/A4 8Ω D-20 ─ ─ Not Fitted D-67
─ ─ Not Fitted M-47 4 5 4/A5 16Ω D-21 ─ ─ Not Fitted D-66
─ ─ Not Fitted M-48 4 6 4/A6 32Ω D-22 ─ ─ Not Fitted D-65
─ ─ Not Fitted M-64 4 7 4/A7 64Ω D-23 ─ ─ Not Fitted D-64
─ ─ Not Fitted M-63 4 8 4/A8 128Ω D-24 ─ ─ Not Fitted D-63
─ ─ Not Fitted M-62 4 9 4/A9 256Ω D-25 ─ ─ Not Fitted D-62
─ ─ Not Fitted M-61 4 10 4/A10 512Ω D-26 ─ ─ Not Fitted D-61
2 13 2/B1 2048Ω M-60 4 11 4/A11 1024Ω D-27
2 14 2/B2 1024Ω M-59 4 12 4/A12 2048Ω D-28
