Page 7.2
PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 7 - MAINTENANCE INFORMATION
Chan.
Resis-
tor
Relay Chan.
Resis-
tor
Relay Chan.
Resis-
tor
Relay Chan.
Resis-
tor
Relay
1 A1 RL1 3 B1 RL48 6 A1 RL1 8 B1 RL48
1 A2 RL2 3 B2 RL47 6 A2 RL2 8 B2 RL47
1 A3 RL3 3 B3 RL46 6 A3 RL3 8 B3 RL46
1 A4 RL4 3 B4 RL45 6 A4 RL4 8 B4 RL45
1 A5 RL5 3 B5 RL44 6 A5 RL5 8 B5 RL44
1 A6 RL6 3 B6 RL43 6 A6 RL6 8 B6 RL43
1 A7 RL7 3 B7 RL42 6 A7 RL7 8 B7 RL42
1 A8 RL8 3 B8 RL41 6 A8 RL8 8 B8 RL41
1 B1 RL16 4 A1 RL49 6 B1 RL16 9 A1 RL49
1 B2 RL15 4 A2 RL50 6 B2 RL15 9 A2 RL50
1 B3 RL14 4 A3 RL51 6 B3 RL14 9 A3 RL51
1 B4 RL13 4 A4 RL52 6 B4 RL13 9 A4 RL52
1 B5 RL12 4 A5 RL53 6 B5 RL12 9 A5 RL53
1 B6 RL11 4 A6 RL54 6 B6 RL11 9 A6 RL54
1 B7 RL10 4 A7 RL55 6 B7 RL10 9 A7 RL55
1 B8 RL9 4 A8 RL56 6 B8 RL9 9 A8 RL56
2 A1 RL17 4 B1 RL64 7 A1 RL17 9 B1 RL64
2 A2 RL18 4 B2 RL63 7 A2 RL18 9 B2 RL63
2 A3 RL19 4 B3 RL62 7 A3 RL19 9 B3 RL62
2 A4 RL20 4 B4 RL61 7 A4 RL20 9 B4 RL61
2 A5 RL21 4 B5 RL60 7 A5 RL21 9 B5 RL60
2 A6 RL22 4 B6 RL59 7 A6 RL22 9 B6 RL59
2 A7 RL23 4 B7 RL58 7 A7 RL23 9 B7 RL58
2 A8 RL24 4 B8 RL57 7 A8 RL24 9 B8 RL57
2 B1 RL32 5 A1 RL65 7 B1 RL32 NOT FITTED RL65
2 B2 RL31 5 A2 RL66 7 B2 RL31 NOT FITTED RL66
2 B3 RL30 5 A3 RL67 7 B3 RL30 NOT FITTED RL67
2 B4 RL29 5 A4 RL68 7 B4 RL29 NOT FITTED RL68
2 B5 RL28 5 A5 RL69 7 B5 RL28 NOT FITTED RL69
2 B6 RL27 5 A6 RL70 7 B6 RL27 NOT FITTED RL70
2 B7 RL26 5 A7 RL71 7 B7 RL26 NOT FITTED RL71
2 B8 RL25 5 A8 RL72 7 B8 RL25 NOT FITTED RL72
3 A1 RL33 5 B1 RL80 8 A1 RL33 NOT FITTED RL80
3 A2 RL34 5 B2 RL79 8 A2 RL34 NOT FITTED RL79
3 A3 RL35 5 B3 RL78 8 A3 RL35 NOT FITTED RL78
3 A4 RL36 5 B4 RL77 8 A4 RL36 NOT FITTED RL77
3 A5 RL37 5 B5 RL76 8 A5 RL37 NOT FITTED RL76
3 A6 RL38 5 B6 RL75 8 A6 RL38 NOT FITTED RL75
3 A7 RL39 5 B7 RL74 8 A7 RL39 NOT FITTED RL74
3 A8 RL40 5 B8 RL73 8 A8 RL40 NOT FITTED RL73
Table 7.1 - 40-296 - 8-Bit Versions - Relay Look-Up Table
(relays highlighted in blue are on the motherboard,
relays highlighted in yellow are on the daughterboard)
