Page 7.3
PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 7 - MAINTENANCE INFORMATION
Chan.
Resis-
tor
Relay Chan.
Resis-
tor
Relay Chan.
Resis-
tor
Relay Chan.
Resis-
tor
Relay
1 A1 RL1 2 A9 RL41 NOT FITTED RL16 4 B5 RL40
1 A2 RL2 2 A10 RL42 NOT FITTED RL15 4 B6 RL39
1 A3 RL3 2 A11 RL43 NOT FITTED RL14 4 B7 RL38
1 A4 RL4 2 A12 RL44 NOT FITTED RL13 4 B8 RL37
1 A5 RL5 NOT FITTED RL45 3 B1 RL12 4 B9 RL36
1 A6 RL6 NOT FITTED RL46 3 B2 RL11 4 B10 RL35
1 A7 RL7 NOT FITTED RL47 3 B3 RL10 4 B11 RL34
1 A8 RL8 NOT FITTED RL48 3 B4 RL9 4 B12 RL33
1 A9 RL9 NOT FITTED RL64 3 B5 RL8 NOT FITTED RL49
1 A10 RL10 NOT FITTED RL63 3 B6 RL7 NOT FITTED RL50
1 A11 RL11 NOT FITTED RL62 3 B7 RL6 NOT FITTED RL51
1 A12 RL12 NOT FITTED RL61 3 B8 RL5 NOT FITTED RL52
NOT FITTED RL13 2 B1 RL60 3 B9 RL4 NOT FITTED RL53
NOT FITTED RL14 2 B2 RL59 3 B10 RL3 NOT FITTED RL54
NOT FITTED RL15 2 B3 RL58 3 B11 RL2 NOT FITTED RL55
NOT FITTED RL16 2 B4 RL57 3 B12 RL1 NOT FITTED RL56
NOT FITTED RL32 2 B5 RL56 4 A1 RL17 NOT FITTED RL57
NOT FITTED RL31 2 B6 RL55 4 A2 RL18 NOT FITTED RL58
NOT FITTED RL30 2 B7 RL54 4 A3 RL19 NOT FITTED RL59
NOT FITTED RL29 2 B8 RL53 4 A4 RL20 NOT FITTED RL60
1 B1 RL28 2 B9 RL52 4 A5 RL21 NOT FITTED RL80
1 B2 RL27 2 B10 RL51 4 A6 RL22 NOT FITTED RL79
1 B3 RL26 2 B11 RL50 4 A7 RL23 NOT FITTED RL78
1 B4 RL25 2 B12 RL49 4 A8 RL24 NOT FITTED RL77
1 B5 RL24 3 A1 RL65 4 A9 RL25 NOT FITTED RL76
1 B6 RL23 3 A2 RL66 4 A10 RL26 NOT FITTED RL75
1 B7 RL22 3 A3 RL67 4 A11 RL27 NOT FITTED RL74
1 B8 RL21 3 A4 RL68 4 A12 RL28 NOT FITTED RL73
1 B9 RL20 3 A5 RL69 NOT FITTED RL29 NOT FITTED RL72
1 B10 RL19 3 A6 RL70 NOT FITTED RL30 NOT FITTED RL71
1 B11 RL18 3 A7 RL71 NOT FITTED RL31 NOT FITTED RL70
1 B12 RL17 3 A8 RL72 NOT FITTED RL32 NOT FITTED RL69
2 A1 RL33 3 A9 RL73 NOT FITTED RL48 NOT FITTED RL68
2 A2 RL34 3 A10 RL74 NOT FITTED RL47 NOT FITTED RL67
2 A3 RL35 3 A11 RL75 NOT FITTED RL46 NOT FITTED RL66
2 A4 RL36 3 A12 RL76 NOT FITTED RL45 NOT FITTED RL65
2 A5 RL37 NOT FITTED RL77 4 B1 RL44 NOT FITTED RL64
2 A6 RL38 NOT FITTED RL78 4 B2 RL43 NOT FITTED RL63
2 A7 RL39 NOT FITTED RL79 4 B3 RL42 NOT FITTED RL62
2 A8 RL40 NOT FITTED RL80 4 B4 RL41 NOT FITTED RL61
Table 7.2 - 40-296 - 12-Bit Versions - Relay Look-Up Table
(relays highlighted in blue are on the motherboard,
relays highlighted in yellow are on the daughterboard)
