Page 7.5
PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 7 - MAINTENANCE INFORMATION
Chan.
Resis-
tor
Relay Chan.
Resis-
tor
Relay Chan.
Resis-
tor
Relay Chan.
Resis-
tor
Relay
1 A1 RL1 1 B17 RL32 2 B9 RL8 3 B1 RL64
1 A2 RL2 1 B18 RL31 2 B10 RL7 3 B2 RL63
1 A3 RL3 1 B19 RL30 2 B11 RL6 3 B3 RL62
1 A4 RL4 1 B20 RL29 2 B12 RL5 3 B4 RL61
1 A5 RL5 1 B21 RL28 2 B13 RL4 3 B5 RL60
1 A6 RL6 1 B22 RL27 2 B14 RL3 3 B6 RL59
1 A7 RL7 1 B23 RL26 2 B15 RL2 3 B7 RL58
1 A8 RL8 1 B24 RL25 2 B16 RL1 3 B8 RL57
1 A9 RL9 2 A1 RL49 2 B17 RL80 3 B9 RL56
1 A10 RL10 2 A2 RL50 2 B18 RL79 3 B10 RL55
1 A11 RL11 2 A3 RL51 2 B19 RL78 3 B11 RL54
1 A12 RL12 2 A4 RL52 2 B20 RL77 3 B12 RL53
1 A13 RL13 2 A5 RL53 2 B21 RL76 3 B13 RL52
1 A14 RL14 2 A6 RL54 2 B22 RL75 3 B14 RL51
1 A15 RL15 2 A7 RL55 2 B23 RL74 3 B15 RL50
1 A16 RL16 2 A8 RL56 2 B24 RL73 3 B16 RL49
1 A17 RL17 2 A9 RL57 3 A1 RL17 3 B17 RL48
1 A18 RL18 2 A10 RL58 3 A2 RL18 3 B18 RL47
1 A19 RL19 2 A11 RL59 3 A3 RL19 3 B19 RL46
1 A20 RL20 2 A12 RL60 3 A4 RL20 3 B20 RL45
1 A21 RL21 2 A13 RL61 3 A5 RL21 3 B21 RL44
1 A22 RL22 2 A14 RL62 3 A6 RL22 3 B22 RL43
1 A23 RL23 2 A15 RL63 3 A7 RL23 3 B23 RL42
1 A24 RL24 2 A16 RL64 3 A8 RL24 3 B24 RL41
1 B1 RL48 2 A17 RL65 3 A9 RL25 NOT FITTED RL65
1 B2 RL47 2 A18 RL66 3 A10 RL26 NOT FITTED RL66
1 B3 RL48 2 A19 RL67 3 A11 RL27 NOT FITTED RL67
1 B4 RL45 2 A20 RL68 3 A12 RL28 NOT FITTED RL68
1 B5 RL44 2 A21 RL69 3 A13 RL29 NOT FITTED RL69
1 B6 RL43 2 A22 RL70 3 A14 RL30 NOT FITTED RL70
1 B7 RL42 2 A23 RL71 3 A15 RL31 NOT FITTED RL71
1 B8 RL41 2 A24 RL72 3 A16 RL32 NOT FITTED RL72
1 B9 RL40 2 B1 RL16 3 A17 RL33 NOT FITTED RL73
1 B10 RL39 2 B2 RL15 3 A18 RL34 NOT FITTED RL74
1 B11 RL38 2 B3 RL14 3 A19 RL35 NOT FITTED RL75
1 B12 RL37 2 B4 RL13 3 A20 RL36 NOT FITTED RL76
1 B13 RL36 2 B5 RL12 3 A21 RL37 NOT FITTED RL77
1 B14 RL35 2 B6 RL11 3 A22 RL38 NOT FITTED RL78
1 B15 RL34 2 B7 RL10 3 A23 RL39 NOT FITTED RL79
1 B16 RL33 2 B8 RL9 3 A24 RL40 NOT FITTED RL80
Table 7.4 - 40-296 - 24-Bit Versions - Relay Look-Up Table
(relays highlighted in blue are on the motherboard,
relays highlighted in yellow are on the daughterboard)
