Page 7.6
PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 7 - MAINTENANCE INFORMATION
Figure 7.1 - 40-296 Motherboard Component Layout
RL8 RL7 RL6 RL5 RL4 RL3 RL2 RL1
RL16 RL15 RL14 RL13 RL12 RL11 RL10 RL9
RL24 RL23 RL22 RL21 RL20 RL19 RL18 RL17
RL32 RL31 RL30 RL29 RL28 RL27 RL26 RL25
RL40 RL39 RL38 RL37 RL36 RL35 RL34 RL33
RL48 RL47 RL46 RL45 RL44 RL43 RL42 RL41
RL56 RL55 RL54 RL53 RL52 RL51 RL50 RL49
RL64 RL63 RL62 RL61 RL60 RL59 RL58 RL57
RL68 RL67 RL66 RL65
RL72 RL71 RL70 RL69
RL76 RL75 RL74 RL73
RL80 RL79 RL78 RL77
Figure 7.2 - 40-296 Daughterboard Component Layout
RL1 RL2 RL3 RL4 RL5 RL6 RL7 RL8
RL9 RL10 RL11 RL12 RL13 RL14 RL15 RL16
RL17 RL18 RL19 RL20 RL21 RL22 RL23 RL24
RL73 RL74 RL75 RL76 RL77 RL78 RL79 RL80
RL25 RL26 RL27 RL28 RL29 RL30 RL31 RL32
RL33 RL34 RL35 RL36 RL37 RL38 RL39 RL40
RL41 RL42 RL43 RL44 RL45 RL46 RL47 RL48
RL49 RL50 RL51 RL52 RL53 RL54 RL55 RL56
RL57 RL58 RL59 RL60 RL61 RL62 RL63 RL64
RL65 RL66 RL67 RL68 RL69 RL70 RL71 RL72
