PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 7 - MAINTENANCE INFORMATION
Table 7.5 - Test Result Limits For 40-296
Resistor
Nominal
Value
Maximum
Value
Minimum
Value
PATH 0Ω See Note1
See Note1
R1 1Ω 0.955Ω
0.795Ω
R2 2Ω 1.96Ω
1.79Ω
R3 4Ω 3.97Ω
3.78Ω
R4 8Ω 7.99Ω
7.76Ω
R5 16Ω 16.03Ω
15.72Ω
R6 32Ω 32.11Ω
31.64Ω
R7 64Ω 64.27Ω
63.48Ω
R8 128Ω 128.6Ω
127.2Ω
R9 256Ω 257.2Ω
254.5Ω
R10 512Ω 514.5Ω
509.2Ω
R11 1024Ω 1029.1Ω
1018.7Ω
R12 2048Ω 2058.2Ω
2037.6Ω
R13 4096Ω 4116Ω
4075Ω
R14 8192Ω 8233Ω
8151Ω
R15 16384Ω 16466Ω
16302Ω
R16 32768Ω 32932Ω
32604Ω
R17 65536Ω 65864Ω
65208Ω
R18 131072Ω 132383Ω
129761Ω
R19 262144Ω 264765Ω
259522Ω
R20 524288Ω 529531Ω
519045Ω
R21 1048576Ω 1059062Ω
1038090Ω
R22 2097152Ω 2118123Ω
2076180Ω
R23 4194304Ω 4236247Ω
4152361Ω
R24 8388608Ω 8472494Ω
8304722Ω
Note 1: PATH resistance limits are 0.5Ω to 2Ω for 8-bit modules, 0.75Ω to 3Ω for 12-bit,
1Ω to 4Ω for 16-bit and 1.5Ω to 6Ω for 24-bit channels.
Note 2: All results in red are taken with the DMM offset to remove the PATH result form the answer
The test should be repeated for each channel of the module.
To aid users to establish test limits the following generic tables should be used for the standard modules. The tables
can be copied to record the results for each channel.
Similar principles can be applied to custom modules, if guidance is needed please consult your Pickering Interfaces
representative.
