Page 7.9
PROGRAMMABLE POTENTIOMETER MODULE 40-296
pickering
SECTION 7 - MAINTENANCE INFORMATION
Table 7.6 - Calibration Test Results For 40-296 (8-Bit Versions)
Serial Number:
Channel Number:
Date of Test:
Operator’s Name:
Test Equipment Used:
Resistance
Setting
Nominal
Value
Measured
Value
Maximum
Value
Minimum
Value
Result
(delete as
appropriate)
PATH 0Ω See Note1
See Note1 Pass / Fail
R1 1Ω 0.955Ω
0.795Ω Pass / Fail
R2 2Ω 1.96Ω
1.79Ω Pass / Fail
R3 4Ω 3.97Ω
3.78Ω Pass / Fail
R4 8Ω 7.99Ω
7.76Ω Pass / Fail
R5 16Ω 16.03Ω
15.72Ω Pass / Fail
R6 32Ω 32.11Ω
31.64Ω Pass / Fail
R7 64Ω 64.27Ω
63.48Ω Pass / Fail
R8 128Ω 128.6Ω
127.2Ω Pass / Fail
Note 1: PATH resistance limits are 0.5Ω to 2Ω.
Note 2: All results in colour are taken with the DMM offset to remove the PATH result form the answer.
