SECTION 3 - INSTALLATION
Page 3.1
PCI REED RELAY CARD 50-110 / 115 / 120 / 125
pickering
SECTION 3 - INSTALLATION
Figure 3.1 - Inserting a PCI Card into a PC Chassis
kg
PREOPERATION CHECKS (UNPACKING)
1. Check the card for transport damage and report any damage immediately to Pickering Interfaces.
Do not attempt to install the product if any damage is evident.
2. Position the PC chassis relative to any other equipment the card(s) will connect with. Ensure the chassis is
not connected to the electrical supply.
3. Ensure that the designated area for the chassis containing the card(s) is of at and solid construction to
withstand and support the total weight of the PC Chassis and cards.
SECTION 3 - INSTALLATION
!
Refer to the Warnings and Cautions at the front of this manual
Modular products require installation in a suitable chassis. The card is designed for indoor use only.
To Next Page
