Page 7.3
VERY HIGH DENSITY MULTIPLEXER CARD 50-670A
pickering
SECTION 7 - MAINTENANCE INFORMATION
Table 7.2 - Multiplexer 50-670A-021-99/1 (99 Channel, 1-Pole): Relay Cross Reference
Channel Pole Relay Channel Pole Relay
1 1 RL81 51 1 RL35
2 1 RL82 52 1 RL36
3 1 RL83 53 1 RL37
4 1 RL84 54 1 RL38
5 1 RL85 55 1 RL39
6 1 RL86 56 1 RL40
7 1 RL87 57 1 RL41
8 1 RL88 58 1 RL42
9 1 RL89 59 1 RL43
10 1 RL90 60 1 RL44
11 1 RL91 61 1 RL45
12 1 RL92 62 1 RL46
13 1 RL93 63 1 RL47
14 1 RL94 64 1 RL48
15 1 RL95 65 1 RL17
16 1 RL96 66 1 RL18
17 1 RL65 67 1 RL19
18 1 RL66 68 1 RL20
19 1 RL67 69 1 RL21
20 1 RL68 70 1 RL22
21 1 RL69 71 1 RL23
22 1 RL70 72 1 RL24
23 1 RL71 73 1 RL25
24 1 RL72 74 1 RL26
25 1 RL73 75 1 RL27
26 1 RL74 76 1 RL28
27 1 RL75 77 1 RL29
28 1 RL76 78 1 RL30
29 1 RL77 79 1 RL31
30 1 RL78 80 1 RL32
31 1 RL79 81 1 RL1
32 1 RL80 82 1 RL2
33 1 RL49 83 1 RL3
34 1 RL50 84 1 RL4
35 1 RL51 85 1 RL5
36 1 RL52 86 1 RL6
37 1 RL53 87 1 RL7
38 1 RL54 88 1 RL8
39 1 RL55 89 1 RL9
40 1 RL56 90 1 RL10
41 1 RL57 91 1 RL11
42 1 RL58 92 1 RL12
43 1 RL59 93 1 RL13
44 1 RL60 94 1 RL14
45 1 RL61 95 1 RL15
46 1 RL62 96 1 RL16
47 1 RL63 97 1 RL100
48 1 RL64 98 1 RL101
49 1 RL33 99 1 RL99
50 1 RL34 Isolation 1 RL98
Not Used RL97
